68 / 94
68
UBand™ Contactless Silicone Wristband
UBand™ Technical Speci cations
Chip Type:
MIFARE 1K
Operating Frequency:
13.56 MHz
EEPROM Size:
1024 Byte
(8192 Bit)
Memory Organization:
16 Sectors, 4
Blocks of 16 Bytes
Unique Serial Number
(UID):
4 Byte (32 bit)
RF Interface:
ISA 14443A
Data Retention (Years):
10
Write Endurance (Cycles):
100,000
Read / Write Range:
1.5”/ 3.8 cm
Actual wristband colors may vary, especially day glow colors.
AVAILABLE COLORS
WHITE
CRANBERRY
DAY GLOW GREEN
ORANGE
LIGHT PINK
GRAY
GOLD
LIGHT BLUE
BLUE
HOT PINK
FOREST GREEN
BLACK
YELLOW
GRAPE
TEAL
KELLY GREEN
RED
AQUA
KHAKI
LAVENDER
UBand™ is a new contactless technology solution that is
ideal for colleges and universities, combining multi-faceted
MIFARE™ technology with the convenience and exibility of
a silicone wristband.
• Wearability -
Unlike cards, which need to be carried in a pocket
or on an attachment, UBand remains attached to the user
naturally, increasing the likelihood of use while decreasing the
likelihood of loss or theft.
• Durability -
UBand is waterproof, sweatproof and can stand up
to the rigors and wear and tear of campus life.
• Flexibility -
UBand’s exibility is two-fold: material and
usage. UBand’s silicone rubber construction allows the band to
stretch around the hand for easy, comfortable removal. MIFARE
technology allows UBand to be customized to whatever uses a
campus needs, including access, payments and more. Include
the features you need and leave out those you don’t.
• Customizability -
20 color options make it easy to nd one to
suit any college or university, while three di erent wrist sizes
(6", 7", 8") mean there is a t for everyone. With custom
printing available in emboss, deboss, or silk screen, it's simple
to make the UBand unique.
Book Store
Laundry
Dorm Room
Fitness
Center
Vending
Machines
Printers
O -Site
Vendors
Access
Control
UBand
™
- a new campus
technology solution!
Applications of a Card,
Convenience of aWristband!
NEW!
UBand™
Item #
Description
MOQ
UBAND1K-6-_ _ _ _
6" Small
100
UBAND1K-7-_ _ _ _
7" Medium
100
UBAND1K-8-_ _ _ _
8" Large
100
Substitute the _ _ _ _'s with the band color (shown above).
