68

UBand™ Contactless Silicone Wristband

UBand™ Technical Speci cations

Chip Type:

MIFARE 1K

Operating Frequency:

13.56 MHz

EEPROM Size:

1024 Byte

(8192 Bit)

Memory Organization:

16 Sectors, 4

Blocks of 16 Bytes

Unique Serial Number

(UID):

4 Byte (32 bit)

RF Interface:

ISA 14443A

Data Retention (Years):

10

Write Endurance (Cycles):

100,000

Read / Write Range:

1.5”/ 3.8 cm

Actual wristband colors may vary, especially day glow colors.

AVAILABLE COLORS

WHITE

CRANBERRY

DAY GLOW GREEN

ORANGE

LIGHT PINK

GRAY

GOLD

LIGHT BLUE

BLUE

HOT PINK

FOREST GREEN

BLACK

YELLOW

GRAPE

TEAL

KELLY GREEN

RED

AQUA

KHAKI

LAVENDER

UBand™ is a new contactless technology solution that is

ideal for colleges and universities, combining multi-faceted

MIFARE™ technology with the convenience and exibility of

a silicone wristband.

• Wearability -

Unlike cards, which need to be carried in a pocket

or on an attachment, UBand remains attached to the user

naturally, increasing the likelihood of use while decreasing the

likelihood of loss or theft.

• Durability -

UBand is waterproof, sweatproof and can stand up

to the rigors and wear and tear of campus life.

• Flexibility -

UBand’s exibility is two-fold: material and

usage. UBand’s silicone rubber construction allows the band to

stretch around the hand for easy, comfortable removal. MIFARE

technology allows UBand to be customized to whatever uses a

campus needs, including access, payments and more. Include

the features you need and leave out those you don’t.

• Customizability -

20 color options make it easy to nd one to

suit any college or university, while three di erent wrist sizes

(6", 7", 8") mean there is a t for everyone. With custom

printing available in emboss, deboss, or silk screen, it's simple

to make the UBand unique.

Book Store

Laundry

Dorm Room

Fitness

Center

Vending

Machines

Printers

O -Site

Vendors

Access

Control

UBand

- a new campus

technology solution!

Applications of a Card,

Convenience of aWristband!

NEW!

UBand™

Item #

Description

MOQ

UBAND1K-6-_ _ _ _

6" Small

100

UBAND1K-6-_ _ _ _

7" Medium

100

UBAND1K-6-_ _ _ _

8" Large

100

Substitute the _ _ _ _'s with the band color (shown above).
